用途：Use
|
|
適合于面粉、洗衣粉、精細白糖、奶粉、奶茶粉、果味粉、葡萄糖粉、調料、食品添加劑、農藥、保健茶粉、中藥粉等粉狀物料的自動化包裝。
|
|
Suitable for automatic packaging powder materials like all kinds of flour ,washing powder, fine sugar,milk powder,glucose,seasoning,food additive,pesticide,and Chinese medicine.
|
|
|
|
特點：Features
|
1.進口PLC、人機界面控制系統，觸摸屏操作簡便、直觀。
2.伺服送膜系統，定位準確，封切位置均采用自動糾偏裝置，自動化程度高。
3.采用智能溫控器、溫度控制準確，保證封口美觀、平整。
4.完善的自動報警保護功能，將損耗減到最低。
5.本機與計量裝置配套即可自動完成送料、計量、充填制袋、日期打印的全部包裝過程，并自動完成計數。
6.制袋形式：本機可以根據客戶需要制成枕式袋、打孔掛袋。
|
Imported PLC control system, simple-operating, visual touch screw.
Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device, high automation.
Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
Perfect automatic alarming protective function, reduce the consumption up to the lowest.
When the machine is combined with metering equipments, full packaging process including automatic feeding, metering, bag filling, date printing and automatic counting is completed.
Type of bag making: according to customer's demand, the machine can produce
pillow bags, punched hanging bags.
|
|
|
|
主要技術參數 Main Technical parameter
|
|
|
|
包裝速度
|
Packing speed
|
15-70bags/min
|
|
制袋尺寸
|
Bag-making size
|
(L)80-350mm(W)80-250mm
|
|
計量范圍
|
Filling range
|
150-2000ml
|
|
包裝膜寬
|
Film width
|
180-520mm
|
|
包裝材料
|
Packing materials
|
OPP/CPP PET/PE 等復合材料
|
|
薄膜厚度
|
Film thickness
|
0.04-0.08mm
|
|
耗氣量
|
Air consumption
|
0.36m3/min 0.6MPa
|
|
電源功率
|
Power supply
|
AC220V 50Hz 3.5kw
|
|
機器尺寸
|
Machine dimensions
|
(L)1600×(W)1050×(H)1750mm
|
|
整機重量
|
Machine weight
|
680kg
|
|
|
